Fanless Industrial Panel PC - UL Certified
Industrial panel PC integrating the latest Intel processors into a rugged aluminum chassis with an IP65/66-rated dust/water resistant front bezel for harsh working environments and industrial applications. The PC9XXX ensures reliability and performance while being able to keep power costs down to a minimum. These panel PCs are available in a wide range of LCD sizes from 7-inch to 24-inch and feature a Resistive or Projected Capacitive type touch screen. Furthermore, the touch panel PCs feature various I/O ports including high-speed USB 3.0 ports, wireless LAN, COM ports, and video ports. The PC9XXX fanless panel PC series is a reliable, energy-efficient computer ideal for HMI applications, data acquisition, and manufacturing systems.
Fanless Industrial Panel PC - UL Certified
7" to 21.5" fanless panel PC series designed to meet UL safety requirements and standards. The panel PCs feature an aluminum due-casting chassis with an IP66 rated front bezel, Intel Celeron N2930 / 6th Gen. Intel Core i3 CPU, multiple I/O ports, Resistive type touchscreen, and a 9 to 36V DC power input. Option for Projected Capacitive touchscreen, 1000-nit high brightness display, optical bonding, mini PCIe slot, external AC power adapter, wide operating temperature range, and Windows OS.
-
![]()
- 7 inch 800 x 480 350-nit industrial LCD panel
- Die-cast aluminum bezel with IP66 rated waterproof front bezel
- Intel Celeron N2930 1.83GHz quad-core CPU with DDR3L memory
- 2 x USB 3.0, 1 x RS-232/422/485, 1 x RS-232, 1 x Audio, 2 x GbE LAN
- Resistive type touch screen, option for Projected Capacitive touch screen
- Option for 1000-nit high brightness display or optical bonding
- Option for -20°C to 60°C wide range working temperature
- Wide range 9 to 36V DC power input
-
![]()
- 8 inch 800 x 600 350-nit industrial LCD panel
- Die-cast aluminum bezel with IP66 rated waterproof front bezel
- Intel Celeron N2930 1.83GHz quad-core CPU with DDR3L memory
- 2 x USB 3.0, 1 x RS-232/422/485, 1 x RS-232, 1 x Audio, 2 x GbE LAN
- Resistive type touch screen, option for Projected Capacitive touch screen
- Option for 1000-nit high brightness display or optical bonding
- Option for -20°C to 60°C wide range working temperature
- Wide range 9 to 36V DC power input
-
![]()
- 10.1 inch 1280 x 800 350-nit industrial LCD panel
- Die-cast aluminum bezel with IP66 rated waterproof front bezel
- Intel Celeron N2930 1.83GHz quad-core CPU with DDR3L memory
- 2 x USB 3.0, 1 x RS-232/422/485, 1 x RS-232, 1 x Audio, 2 x GbE LAN
- Resistive type touch screen, option for Projected Capacitive touch screen
- Option for 1000-nit high brightness display or optical bonding
- Option for -20°C to 60°C wide range working temperature
- Wide range 9 to 36V DC power input
-
![]()
- 12.1 inch 800 x 600 450-nit industrial LCD panel
- Die-cast aluminum bezel with IP66 rated waterproof front bezel
- Intel Celeron N2930 CPU / 8th generation Intel Core i3-8145UE
- 2 x USB 3.0, 1 x RS-232/422/485, 1 x RS-232, 1 x Audio, 2 x GbE LAN
- Resistive type touch screen, option for Projected Capacitive touch screen
- Option for 1000-nit high brightness display or optical bonding
- Option for -20°C to 60°C wide range working temperature
- Wide range 9 to 36V DC power input
-
![]()
- 15 inch 1024 x 768 450-nit industrial LCD panel
- Die-cast aluminum bezel with IP66 rated waterproof front bezel
- Intel Celeron N2930 CPU / 8th generation Intel Core i3-8145UE CPU
- 2 x USB 3.0, 1 x RS-232/422/485, 1 x RS-232, 1 x Audio, 2 x GbE LAN
- Resistive type touch screen, option for Projected Capacitive touch screen
- Option for 1000-nit high brightness display or optical bonding
- Option for -20°C to 60°C wide range working temperature
- Wide range 9 to 36V DC power input
-
![]()
- 15.6 inch 1366 x 768 300-nit industrial LCD panel
- Die-cast aluminum bezel with IP66 rated waterproof front bezel
- Intel Celeron N2930 CPU / 6th generation Intel Core i3-6100 CPU
- 2 x USB 3.0, 1 x RS-232/422/485, 1 x RS-232, 1 x Audio, 2 x GbE LAN
- Resistive type touch screen, option for Projected Capacitive touch screen
- Option for 1000-nit high brightness display or optical bonding
- Option for additional I/O ports and mini PCIe slot full size
- Wide range 9 to 36V DC power input
-
![]()
- 17 inch 1280 x 1024 350-nit industrial LCD panel
- Die-cast aluminum bezel with IP66 rated waterproof front bezel
- Intel Celeron N2930 CPU / 6th generation Intel Core i3-6100 CPU
- 2 x USB 3.0, 1 x RS-232/422/485, 1 x RS-232, 1 x Audio, 2 x GbE LAN
- Resistive type touch screen, option for Projected Capacitive touch screen
- Option for 1000-nit high brightness display or optical bonding
- Option for additional I/O ports and mini PCIe slot full size
- Wide range 9 to 36V DC power input
-
![]()
- 18.5 inch 1366 x 768 350-nit industrial LCD panel
- Die-cast aluminum bezel with IP66 rated waterproof front bezel
- Intel Celeron N2930 CPU / 8th generation Intel Core i3-8145UE CPU
- 2 x USB 3.0, 1 x RS-232/422/485, 1 x RS-232, 1 x Audio, 2 x GbE LAN
- Resistive type touch screen, option for Projected Capacitive touch screen
- Option for 1000-nit high brightness display or optical bonding
- Option for additional I/O ports and mini PCIe slot full size
- Wide range 9 to 36V DC power input
-
![]()
- 21.5 inch 1920 x 1080 250-nit industrial LCD panel
- Die-cast aluminum bezel with IP66 rated waterproof front bezel
- Intel Celeron N2930 CPU / 8th generation Intel Core i3-8145UE CPU
- 2 x USB 3.0, 1 x RS-232/422/485, 1 x RS-232, 1 x Audio, 2 x GbE LAN
- Resistive type touch screen, option for Projected Capacitive touch screen
- Option for 1000-nit high brightness display or optical bonding
- Option for additional I/O ports and mini PCIe slot full size
- Wide range 9 to 36V DC power input
UL CERTIFICATION
PC9XXX UL Certification
