1080P / 4K LCD Monitor
Rackmount monitor series provides VGA, DVI, HDMI, and display port video inputs. The size of the casing ranges from 7U to 9U high with screen size variations starting from 16.2 to 23 inches with full HD or 4K display resolution. Option for S-video / BNC / DVI video input, touch screen, and DC power supply.
1080P / 4K LCD Monitor
16.2" to 23" widescreen rackmount LCD monitor integrated into a 7U to 9U high rackmount monitor enclosure. Option for touch screen, S-Video / BNC / SDI input, and DC power supply.
-
![]()
- 9U high rackmount monitor
- 23.8 inch 3840 x 2160 4K industrial LCD monitor
- Option for Resistive, Infrared, or PCAP type touch screen
- DP 1.2 + HDMI 1.4 + HDMI 2.0 video input
- Option for 3G/HD/SD-SDI input & MCS control
- PIP Sub-screen & PBP Dual-screen viewing efficiency
- External 100/240 auto-sensing AC power adapter
- Option for 12V / 24V / 48V / 125V / 250V DC power
-
![]()
- 6U high rackmount monitor
- 17.3 inch 1920 x 1080 Full HD industrial LCD monitor
- Option for multiple or single point touch screen
- VGA + DVI-D video input
- Option for HDMI, DP, Audio, 3G/HD/SD-SDI input
- External 100/240 auto-sensing AC power adapter
- Option for 12V / 24V / 48V / 125V / 250V DC power
-
![]()
- 6U high rackmount monitor
- 16.2 inch 1920 x 1200 WUXGA industrial LCD monitor
- Option for Resistive type touch screen monitor
- Option for IP65/NEMA4 rated front bezel
- VGA + DVI-D + HDMI video input
- Option for DP, Audio, 3G/HD/SD-SDI input
- External 100/240 auto-sensing AC power adapter
- Option for 12V / 24V / 48V / 125V / 250V DC power
-
![]()
- 7U high rackmount monitor
- 19 inch 1440 x 900 widescreen industrial LCD monitor
- Option for Resistive or Capacitive type touch screen
- Option for IP65/NEMA4 rated front bezel
- VGA + DVI-D video input
- Option for BNC, HDMI, Audio, or SDI input
- External 100/240 auto-sensing AC power adapter
- Option for 12V / 24V / 48V / 125V / 250V DC power
-
![]()
- 8U high rackmount monitor
- 21.5 inch 1920 x 1080 Full HD industrial LCD monitor
- Option for multiple or single point touch screen
- Option for IP65 / NEMA4 rated front bezel
- VGA + DVI-D video input
- Option for HDMI, DP, or 3G/HD/SD-SDI input
- External 100/240 auto-sensing AC power adapter
- Option for 12V / 24V / 48V / 125V / 250V DC power
REFERENCES
Everything You Need to Know About 4K Display
4K simply means a clearer picture as it offers more pixels on the screen. Nowadays, the industry named 1080P resolution after image height and named 4K after image width. The pixels of 4K display creates images that are crisper and capable of showing more details than standard HD displays. With HD 1080p screens, the images offer only a 1920 x 1080 resolution while 4K screens provide about 8 million pixels. On the other hand, it means users can fit every pixel from 1080p set onto one-quarter of a 4K screen. Therefore, 4K resolution provides double times what the current 1080P set can display.
