Military-grade embedded computer powered by the Intel Core i7-7700T 2.9GHz quad-core processor with 1 x 10G Base-T Ethernet, 3 x USB ports, 1 x HDMI output, and 1 x RS-232. The embedded computer can be deployed in harsh working environments as it is designed to withstand wide operating temperatures from -20°C to 65°C and has a fully IP67 rated chassis with MIL-STD-810G/461F compliance.
IP67 Rated Fanless Embedded PC with Intel Core i7-9850HL CPU - FES9281

FES9281

Fanless Compact Embedded PC w/ NVIDIA RTX 3000 Graphic Card & Intel 9th Gen. Core i7-9700TE CPU - FES9281-CU02

FES9281-CU02

FES9282

  • Fully IP67 rated fanless embedded microbox
  • Intel Core i7-7700T 2.9GHz quad-core CPU
  • 32GB DDR4 2133/2400 MHz memory
  • 1 x M.2 B-key and  1 x 2.5"removable storage bay
  • 3 x USB 2.0, 1 x RS-232, 1 x HDMI output
  • 1 x GbE LAN and 1 x 10G Base-T Ethernet
  • -20°C to 65°C wide range working temperature
  • MIL-STD-810G & MIL-STD-461F compliance
  • 9 to 36V DC power input
Availability: In stock
SKU
FES9282
Military-grade embedded PC with the Core i7-6600U 2.6GHz CPU, full IP67 rated rugged enclosure, 10G Base-T Ethernet, and -20° to 65°C wide range working temperature.
Material
Full IP67 rugged enclosure
Embedded Board
CPU: Intel Core i7-7700T 2.9 GHz, Quad-Core
Chipset: H110/Q170 chipset
Memory: DDR4 2133/2400 MHz 32GB
Storage: 1 x M.2 B-key, 1 x 2.5"removable storage bay
BIOS: AMI 128Mbit Flash
WiFi: 802.11 b/g/n/ac (Optional)
Ethernet
Intel i211-AT Ethernet Controller
Intel i219-LM Ethernet Connection
I/O Port
1 x DC Input - J1 (D38999/24WD5SN)
3 x USB 2.0 - J2 (D38999/24WH53SN)
1 x RS232 - J2 (D38999/24WH53SN)
1 x GbE LAN - J2 (D38999/24WH53SN)
1 x HDMI output - J2 (D38999/24WH53SN)
1 x 10G Base-T Ethernet - J3 (D38999)
1 x Power On/Off button
1 x Power LED indicator
1 x HDD LED indicator
Power Supply
9 to 36V DC input
Weight
5 to 6 kg / 11 to 13 lb for identity
Dimension
90.4 (W) x 9.84 (D) x 3.54 (H) inches
250.0 (W) x 250.0 (D) x 90 (H) mm
Environmental
Operating Temperature: -20° to 65°C
Operating Humidity: 5% to 95%, non-condensing
Storage Temperature: -40°C to 80°C
Reliability: MIL-STD-810G compliance
EMI: MIL-STD-461F compliance
Durability: MIL-STD-810G compliance
IP Level: Full IP67

FES9282:
Full IP67 rated fanless embedded system, Intel Core i7-7700T 2.9GHz CPU, 3 x USB 2.0 + 1 x RS-232 + 1 x HDMI output + 1 x GbE LAN + 1 x 10G Base-T Ethernet, 9 to 36V DC power input, -20°C to 65°C wide range working temperature, MIL-STD-810G / MIL-STD-461F compliance.

Document
Description
Download Link
file iconFES9282-SP(V1-2).pdf
Spec Sheet
file iconFES9282-PIN.pdf
PIN Assignment
