Rackmount monitor with a 20.1 inch 1152 x 900 (Direct) / 1600 x 1200 (Native) industrial LCD monitor, SUN micro resolution, VGA + DVI-D video input, front OSD control, and a 9U high rackmount monitor enclosure. Option for HDMI / Audio / 3G-SDI input, Resistive type touch sceen, and DC power input.
Loading...
8U 19

RMS8190

RM6173 7U 17

RM6173

RMS9200

  • 9U high rackmount monitor
  • 20.1 inch 1600 x 1200 industrial LCD monitor
  • Supports 1152 x 900 SUN Micro resolution
  • VGA + DVI-D video input, option for HDMI or 3G-SDI input
  • Option for Resistive type touch screen - USB
  • External 100/240 auto-sensing AC power input
  • Option for 12V / 24V / 48V / 125V DC power input
$1,624.00
Availability: In stock
SKU
RMS9200
Email
20.1" rackmount monitor with 1152 x 900 (Direct) / 1600 x 1200 (Native) resolution, VGA + DVI-D video input, 100/240VAC power input, and a 9U high rackmount enclosure.
Construction
Heavy-duty steel
LCD panel
Size: 20.1 inch
Resolution: 1152 x 900 (Direct) / 1600 x 1200 (Native)
Brightness (cd/m²): 300
Contrast Ratio (typ.): 800:1
Viewing Angle (H/V): 178° x 178°
Active Area (mm): 408H x 306V
Colors: 16.7 M
Backlight: CCFL
MTBF (hrs): 45,000
Touch Screen (Option)
Option for Resistive type touch screen - USB
Video input
VGA + DVI-D video input
Option for HDMI / Audio / 3G-SDI input
Front panel control
Power on/off switch
OSD membrane switch
Connector
1 x VGA + 1 DVI-D
Power Supply
Input: Auto-sensing 100 to 240VAC, 50 / 60Hz
Power Consumption: Max. 45W, Standby 2W
Option for 12V / 24V / 48V / 125V DC power input
Mounting
9U high rackmount monitor
For standard 19 inch wide rackmount cabinet
Casing Color
Black front panel (RAL 9005)
Weight
18.7 lb / 8.5 kg
Dimension
18.9"(W) x 2.5"(D) x 15.7"(H)
Environmental
Operating Temperature: 0°C to 55°C
Storage Temperature: -20°C to 60°C
Relative Humidity: 5~90%, non-condensing
Shock: 10G acceleration (11 ms duration)
Vibration: 10~300Hz 0.5G RMS random vibration
Safety
FCC, CE

RMS9200:
20.1 inch 1280 x 1024 (Direct) / 1600 x 1200 (Native) industrial LCD monitor, VGA + DVI-D video input, 100/240VAC power input, 9U high rackmount monitor enclosure, Black color. Option for HDMI / Audio / 3G-SDI input, Resistive type touch screen, and DC power input.

Document
Description
Download Link
file iconRMS9200-SP.pdf
Spec Sheet
file iconRMS9200-INST.pdf
Installation Guide
file iconRMS9200-UM.pdf
User Manual
  • RMS9200
    20.1 inch 1600 x 1200 industrial LCD monitor
    Supports 1152 x 900 SUN Micro resolution
    VGA + DVI-D video input, option for HDMI or 3G-SDI input
    Option for Resistive type touch screen- USB
    External 100/240 auto-sensing AC power input
    Option for 12V / 24V / 48V / 125V DC power input
    9U high rackmount monitor
    Starting at:
    $1,624.00
RMS9200
$1,624.00

PRODUCT DESCRIPTION
The 20.1 inch  1600 x 1200 / 1152 x 900 Sun Micro native resolution industrial monitor is an active type of digital to digital which connects to the onboard conversion board. The rack-mount monitor comes with a standard VGA and DVI-D connector on the back of the rackmount monitor for your rack-mount server connection. Option for HDMI, Audio, or 3G-SDI input. The rackmount monitor offers a 20-inch diagonal LCD with 300nit brightness. Excellent display quality is supported by a maximum contrast ratio of 800:1 and a resolution up to 1600 x 1200 pixels for the monitor. The LCD display 1152 x 900 supports Sun Micro resolution. It provides a 178 degree horizontal and 178-degree vertical viewing angle for unparalleled viewing ability. The OSD function lets you adjust the monitor for contrast, balance, horizontal position, vertical position, phase, and brightness. It will display 16.7M colors (True color). All the power on/off switch and OSD buttons are located on the front of the rack mount monitor for easy access.The monitor comes standard with one 6' VGA cable for the industrial monitor. Option for 10' and 15' VGA cable are available. The power input supports an auto-sensing 100 to 240VAC, 50/60Hz input (Max. 45W, Standby 2W) and a power adapter is provided with the monitor. The rackmount monitor is ready to mount into the standard 19" rack mount cabinet, It occupies a 9U high rackmount unit .
