RMNVR5015

PRODUCT DESCRIPTION
A 15 inch LCD rackmount industrial monitor RMNVR-5015 is integrated with the NVR system supporting 4 IP cameras. The monitor of 4-channel Linux embedded NVR with one LAN port brings stable and efficient system operation under a wide range of recording, network management, or system settings. The heavy-duty steel monitor can withstand a wide range of operating temperatures from 23°F to 131°F and 10~95% relative humidity, non-condensing. The front panel controls for a flexible 1-4 channel selected by buttons. The video input accepts DVI. The connectors include one DVI, two USB ports for mouse and USB drive, one RJ45 10/100 Ethernet, one Line-out audio jack, and one optional USB for touch screen. The power supply uses 12V DC power input with external AC to DC power adapter. The LCD panel consists of a 15-inch display with a maximum resolution of 1024 x 768. It has 16.2 million colors (6 bits + FRC), 700:1 contrast ratio, and 250-nits brightness with the option for a 1000-nits high brightness display. The option for a 5-wire resistive type touch screen is available. This unit channels real-time four IP cameras with 1920 x 1080 resolution at each channel. The back of the unit contains one LAN port which connects to all four IP cameras. The internet protocol accepts IPv4, ARP, TCP, UDP, ICMP, NTP, SMTP, HTTP, RTP, RTSP, and RTCP. The recording format is in H.264. The playback is at 23 frames per second per channel. It is equipped with a storage capacity of SATA II with 2TB for recordings. The IP cameras are capable of auto-search under the same domain.
