Fanless industrial touch panel PC with a 12.1" 1024 x 769 (4:3) projected capacitive type touch screen, Celeron 3855U Dual-Core 1.6GHz CPU, 4GB DDR4 memory, mSATA slot, IP64 compliant front panel, lightweight construction, and -20°C to 50°C extended working temperature. Option for Core i5-6300U CPU and panel/rack mounting kit.
Loading...
10.1

FPC80101

15.6

FPC80156

FPC80121

  • 12.1 " 1024 x 768 (4:3) LED LCD monitor
  • Projected capacitive type touch screen with anti-glare
  • Intel Celeron 3855U Dual-Core 1.6GHz CPU
  • 4GB DDR4 memory, max. 8GB
  • 128GB mSATA SSD
  • Built-in 802.11 a/b/g/n/ac wireless module
  • -20°C to 50°C extended working temperature
  • 36W 90~264VAC external power adapter
  • IP64 rated front bezel
Availability: In stock
SKU
FPC80121
Email
12.1" 1024 x 768 light fanless touch panel PC with Celeron 3855U CPU, 4GB DDR4 memory, IP64 rated front panel, and -20°C to 50°C extended working temperature.
Material
PC + ABS plastic on front panel
LCD Panel
Size: 12.1 inch
Resolution: 1024 x 768 (4:3)
Brightness (cd/m²): 500
Contrast Ratio: 700:1
Viewing Angle (H/V): 160° / 160°
Pixel Pitch (mm): 0.240(H) x 0.240(V)
Colors: 16.2M
MTBF (hrs): 50,000
System
CPU: Celeron 3855U Dual Core 1.6GHz CPU
Option for 6th generation Core i5-6300U 2.4GHz CPU
Memory: 4GB DDR4 memory, max. 8GB
Storage: 128GB mSATA SSD
Touch Screen
Projected capacitive type touch screen with anti-glare coating, USB interface (std)
Connectors
1 x RS-232 COM port (RJ-45)
1 x RS-232/422/485 COM port (DB-9)
2 x GbE LAN
2 x USB 3.0, 2 x USB 2.0
1 x HDMI
1 x Power Switch
1 x Reset button
1 x AT/ATX switch
1 x DC jack
Audio
AMP 3W + 3W internal speakers
Camera & Microphone
2-megapixel with low light function, digital microphone
Wireless
IEEE 802.11 a/b/g/n/ac, Bluetooth V4.1
Mounting
Option for panel or rack mounting kit
Power Supply
36W 90~264VAC external power adapter
Color
Black
Weight
11.09 lb / 5.03 kg
Dimension
11.97"(W) x 9.57"(H) x 2.28"(D)
Environmental
Operating Temperature: -20°C to 50°C
Storage Temperature: -30°C to 60°C
Relative Humidity: 10% to 95%, noncondensing
IP Protection
IP64 compliant front panel
Certification
CE / FCC

FPC80121:
12.1" 1024 X 768 fanless panel PC with Celeron 3855U 1.6GHz CPU, 4GB DDR4 memory, 128GB mSATA SSD, built-in 802.11 a/b/g/n/ac wireless module, projected capacitive type touch screen, anti-glare coating, 90 to 264VAC external power adapter, and -20°C to 50°C extended working temperature.

Document
Description
Download Link
file iconFPC80121-SP(V2-1).pdf
Spec Sheet
  • FPC80121
    12.1 " 1024 x 768 (4:3) LED LCD monitor
    Projected capacitive type touch screen with anti-glare
    Intel Celeron 3855U Dual-Core 1.6GHz CPU
    Option for Core i5-6300U 2.4GHz CPU
    4GB DDR4 memory, max. 8GB
    128GB mSATA SSD
    Built-in 802.11 a/b/g/n/ac wireless module
    -20°C to 50°C extended working temperature
    36W 90~264VAC external power adapter
    IP64 rated front bezel
