APS9017



PRODUCT DESCRIPTION
Waterproof panel mount monitor, a stainless steel industrial panel mount monitors with a 17 inch LCD monitor. The enclosure features an easy-to-clean stainless steel construction that is corrosion-resistant. features IP65 rated front bezel, ideal for diverse applications in harsh environments where hygiene is essential, such as the food industry. The industrial-grade 17-inch 1280 x 1024 resolutions LCD with 300 nits of brightness, 1000:1 contrast, and 16.7M color. For outstanding viewing ability, it is available with an optional resistive or GTG touch screen. the onboard video input port offers a direct-VGA signal transmission allowing a regular VGA control card to be used. On-screen display functions provide customers the ability to adjust images with ease.  The back of chassis has VESA mounting patterns and can be used on wall, arm, and panel mounting applications. This stainless steel monitor supports wide voltage power input from 11V to 32VDC to meet the requirements of unstable electricity environments. Besides, the APS series has been proven to work well in environments with temperature ranging from 32°F to 122°F (0°C to +50°C).

APS9017: 17” Stainless Steel Panel Mount Monitor 17” industrial panel mount LCD that supports 1280 x 1024 high resolutions, IP65 rated front bezel with rugged stainless steel enclosure, VGA video input, 11-32V DC power input. Option for resistive or GFG touch screen monitor.

REFERENCES
IP and NEMA Ratings – What Do They Mean?
IP rating refers to the degree of protection against water and dust provided by a computer's enclosure. Dust and water are often found together in industrial environments. Unfortunately, they can also be exceptionally harmful to electrical components. If a computer is being used in an environment where dust and moisture are prevalent, then the IP (Ingress Protection) and NEMA (National Electrical Manufacturer Association) ratings must be considered.

Touch Screen Monitors - Overview
A touch screen acts as an interface between humans and computers in an automation control unit. Unlike keyboards or mice, touch screens provide convenience and user-friendly access to receive information from one computer to another.

What is a mounting solution?
A mounting solution is a collection of different kinds of mounting methods that can help you to know how to mount your product correctly and rapidly.

New Stainless Steel, Waterproof Panel Mount Monitor Series
Available with 15, 17, or 19 inches LCD screens with resistive or GTG touch screen options, the APS series features easy-to-clean stainless steel construction that is corrosion resistant and conform to IP65 rating, offers a perfect solution for the food and pharmaceutical markets
