PRODUCT EOL NOTICE. REPLACEMENT PRODUCT: PMW6190 19" WIDESCREEN OPEN FRAME LCD MONITOR WITH VGA + HDMI + DVI INPUT
19" open frame montior with 1280 x 1024 resolution, VGA video input, and an open frame metal enclosure. The monitor features -30°C to 80°C wide range working temperature and a front mounting brackets.
PM-S0190
- Open frame monitor with front mounting bracket
- 19 inch 1280 x 1024 300-nit LCD monitor
- VGA video input, option for DVI + HDMI input
- Option for Resistive type touch screen
- Option for 1000-nit LCD panel with auto dimming sensor
- -30°C to 80°C wide range working temperature
- Rear power on/off switch & OSD membrane switch
- Front mounting bracket & rear VESA (100 x 100mm) mounting holes
- Internal power supply with Auto-Sensing, AC90 to 260V, 50/60 Hz
Availability:
In stock
SKU
PM-S0190
19" open frame monitor with 1280 x 1024 resolution, VGA video input, AC power supply, VESA mounting holes, and an open frame enclosure with front mounting bracket.
- Material
- Heavy-duty steel
- LCD Panel
- Size: 19 inch
Max Resolution: 1280 x 1024
Brightness (cd/m²): 300
Contrast Ratio (typ) : 800:1
Viewing Angle (H/V): 170° x 160°
Active Area (mm): 376.3(H) x 301.1(V)
Colors: 16.7M
Backlight: LED
MTBF (hrs): 35,000
Option for 1000-nit LCD panel with auto dimming sensor
- Video input
- VGA video input
Option for DVI + HDMI video input
- Touch Screen (Option)
- Resistive type touch screen with USB port
- Rear panel control
- Power on/off switch
OSD membrane switch
- Mounting Type
- Open frame monitor with front mounting bracket
VESA (100 x 100mm) mounting holes
- Connectors
- 1 x VGA port (15 pin Female D-Sub)
1 x PC Audio (Stereo Headphone Jack)
1 x DC Power Plug
- Power supply
- Internal power supply with Auto-Sensing, AC90 to 260V, 50/60 Hz
Power Consumption: 32.2W (Operation), < 2 watt (Power Saving)
- Weight
- 15.43 lb / 7 kg
- Dimension
- 16.61"(W) x 2.36"(D) x 14.61"(H)
- Environmental
- Operating Temperature: -30°C to 80°C
Storage Temperature: -30°C to 80°C
Relative Humidity: 10% ~ 90%, noncondensing
- Certification
- CE, FCC
PM-S0190:
19 inch 1280 x 1024 300-nit high brightness LCD panel, VGA video input, -30°C to 80°C wide range working temperature, VESA (100 x 100 mm) mount, and open frame metal enclosure. Option for 1000-nit high brightness LCD panel with auto dimming sensor, DVI + HDMI video input, and Resistive type touchscreen.
