RMC6343A
3U high rackmount computer featuring the latest Intel processors, standard ATX motherboards, 6 x 5.25" external drive bays, and 7 x PCIe expansion slots in a 3U high 22.1" rackmount chassis.
Key Features
- ✓3U high rackmount computer
- ✓22.1" depth rackmount chassis
- ✓Intel Core Ultra / Core i / AMD Ryzen processors
- ✓Standard ATX motherboard
- ✓7 x PCIe expansion slots
- ✓16GB RAM (Up to 64GB) & 250GB NVMe M.2 SSD
- ✓6 x 5.25" external drive bays
- ✓Dual steel front doors with one keylock
- ✓2U 600W ATX power supply
The RMC6343A is a 3U high rackmount computer supporting the latest Intel processors and standard ATX motherboards. The rackmount PC features 6 x 5.25" external drive bays and 7 x PCIe expansion slots in a 3U high 22.1'" short-depth rackmount chassis. The RMC6343A is fully customizable and provides optional upgrades including additional storage space, removable drive bay options, add-on cards, graphic cards, and more.
| Construction | Heavy duty cold rolled steel |
| Standard ATX M/B | Size: Standard ATX motherboard Processor: RMC6343A-A – Intel Core Ultra Processors RMC6343A-B – AMD Ryzen processors RMC6343A-C –Core i processors Memory: up to 64GB |
| Drive Bays | 6 x 5.25" external external drive bays |
| Expansion Slot | 7 x PCIe expansion slots |
| Front Panel Control | Power ON/OFF button System Reset button |
| Security | Dual steel front doors with one keylock |
| Power Supply | 2U 600W ATX power supply |
| Color | Black |
| Environmental | Operating Temperature: 0°C to 50°C (32°F to 122°F) Humidity: 5~95%, non-condensing |
| Weight | 33.1 lb /15 kg |
| Dimension | 19"(W) x 22.1"(D) x 5.2"(H) |
Available Configurations
RMC6343A-A
3U high rackmount computer with Intel Core Ultra Processors, standard ATX motherboard, 7 x PCIe expansion slots, and a 2U 600w ATX power supply in a 3U high 22.1" depth rackmount chassis.
- ✓ 3U high rackmount computer
- ✓ 22.1" short-depth rackmount chassis
- ✓ Intel Core Ultra Processors
- ✓ Standard ATX motherboard
- ✓ 7 x PCIe expansion slots
RMC6343A-B
3U high rackmount computer with AMD Ryzen processors, standard ATX motherboard, 7 x PCIe expansion slots, and a 2U 600w ATX power supply in a 3U high 22.1" depth rackmount chassis.
- ✓ 3U high rackmount computer
- ✓ 22.1" short-depth rackmount chassis
- ✓ AMD Ryzen processors
- ✓ Standard ATX motherboard
- ✓ 7 x PCIe expansion slots
RMC6343A-C
3U high rackmount computer with Core i processors, standard ATX motherboard, 7 x PCIe expansion slots, and a 2U 600w ATX power supply in a 3U high 22.1" depth rackmount chassis.
- ✓ 3U high rackmount computer
- ✓ 22.1" short-depth rackmount chassis
- ✓ Core i processors
- ✓ Standard ATX motherboard
- ✓ 7 x PCIe expansion slots
