RMC5102
5U rackmount GPU workstation supporting standard ATX M/B, RTX 4090 24GB graphics cards, 8 x expansion slots, and excellent hardware versatility.
Key Features
- ✓5U rackmount GPU workstation
- ✓Standard ATX motherboard
- ✓Intel Core or AMD Ryzen processors
- ✓16GB DDR4 memory (up to 32GB) & 500GB NVMe SSD
- ✓Designed for RTX 4090 24GB graphics card
- ✓Supports 1 x 360mm liquid cooling radiator
- ✓Supports sliding rail mounting holes for quick rail installation
- ✓Includes 1 x front USB Type-C port & 2 x front USB 3.0 ports
- ✓2 x 3.5" internal + 4 x 2.5" internal drive bays
- ✓1000W single ATX power supply
The RMC5102 is a 5U rackmount GPU workstation designed for industrial, high-end business, and home use. It is equipped with a standard ATX motherboard and features Intel powerful Intel Core or AMD Ryzen processors that deliver the computing power needed to run the most demanding applications and programs. One of the most important features of this 5U rackmount GPU workstation is its support for the latest RTX 40 series graphics card from NVIDIA. The RTX 4090 24GB graphics card delivers unmatched performance, making it the perfect choice for demanding 3D graphics applications, gaming, and virtual reality. The workstation also features advanced cooling capabilities with support for a 360mm liquid cooling radiator, ensuring that the system remains cool and stable even under heavy loads. With a 1000W single ATX power supply, the system can handle high power demands without any issues.
| Construction | Heavy duty steel |
| System | Motherboard: Standard ATX motherboard Processor: RMC5102-A: AMD Ryzen processors RMC5102-B: Intel Core i processors Memory: 16GB (2 x 8GB) DDR4, up to 128GB Storage: 500GB NVMe SSD |
| Drive Bays | 2 x 3.5" internal drive bays (compatible with 3 x 2.5") 4 x 2.5" internal drive bays |
| Expansion Slots | Up to 8 x expansion slots |
| Graphics Card | Supports RTX 4090 24GB graphics cards |
| Front Panel Control | 1 x USB Type C port 2 x USB 3.0 ports 1 x Power Status LED Indicator 1 x HDD Activity LED Indicator 2 x LAN Activity LED Indicators |
| Security | Side switch for chassis intrusion security |
| Cooling Fans | Front: 2 x 180mm and 120mm x 3 or 180mm x 2 Rear I/O: 120mm x 1 or 140mm x 1 Rear Fan Cage: 80mm x 2 |
| Liquid CPU Cooler (Option) | Option for 1 x 360mm liquid cooling radiator |
| Limitation of CPU Cooler | Height w/ expansion card retainer: 181mm Height w/o expansion card retainer: 192mm |
| Power Supply | 1000W single ATX power supply Option for 1200W single ATX P/S or 800W mini redundant P/S |
| Limitation of PSU | 160mm ~ 190mm (Removal of 3.5" drive cage eliminates PSU depth limitation) |
| Color | Black |
| Environmental | Operating Temperature: 0°C to 55°C Humidity: 5~95%, non-condensing |
| Operating System | Option for Windows 11 Professional 64-Bit (TPM 2.0 Requited) OS |
| Compliance | CE, FCC, RoHS |
| Expansion Card Size | Length: 455mm (without installing front fans and radiators) Height w/ expansion slot retainer: 157mm Height w/o expansion card retainer: 198mm |
| Weight | 23.37 lb / 10.6 kg |
| Dimension | Incl. Rear Fan Cage: 17.3”(W) x 8.66”(H) x 19.1”(D) Excl. Rear Fan Cage: 17.3”(W) x 8.66”(H) x 20.87”(D) |
This product does not have configurable options.
