KD82212
20.1" 1600 x 1200 industrial LCD monitor with 12-port DVI-D KVM switch, 104-key keyboard with touchpad, and 100/240VAC power input in a 1U high 25.6" depth rackmount drawer.
Key Features
- ✓20.1" rack LCD console drawer
- ✓Supports 1600 x 1200 native resolution
- ✓104-key keyboard with 2-button touchpad - USB
- ✓Integrated 12-port DVI-D KVM switch
- ✓1 x local console
- ✓Option for 6ft or 15ft DVI-D USB KVM cables
- ✓Auto-sensing 100 to 240VAC, 50 / 60Hz power input
- ✓Option for 12V / 24V / 48V / 125V DC power input
- ✓1U high 25.6" (650mm) depth rackmount drawer
KVM rack console with a 20.1 inch 1600 x 1200 industrial LCD monitor, front OSD functions, and a 1U slim design with a molded front handle. The rack console is integrated with a 12-port DVI-D KVM switch that provides easy installation and streamlined access to servers and systems. Option for 6ft or 15ft DVI-D + USB KVM cables.
| Material | Heavy-duty steel |
| LCD Panel | Size: 20.1 inch Native Resolution: 1600 x 1200 Brightness (cd/m²): 300 Contrast Ratio (typ.): 800:1 Colors: 16.7 M Viewing Angle (H/V): 178° x 178° Response Time (ms): 16 Dot Pitch (mm): 0.255 Display Area (mm): 408H x 306V Surface Treatment: Anti-glare, Hard-coating Surface Hardness: 3H Blacklight: CCFL MTBF (hrs): 45,000 |
| Keyboard & pointing device | 104-key keyboard with 2-button touchpad (combo free) |
| KVM port | Number of Ports: 12 x DVI KVM ports Connector: DVI-D connector + USB 3.0 connector (for keyboard, mouse & audio) |
| KVM Usage | Advanced user profiles and configurable on screen display (OSD) & hotkey combination Multilingual on screen display menu Supports eight characters password protection |
| Front Panel Control | Power on/off switch OSD (on screen display) 1 x bank number LED indicator 12 x KVM ports LED indicators for on-line / Active / Remote 10 x KVM channel membrane buttons 1 x bank membrane button |
| Compatibility | Hardware: HP / IBM / Dell PC, Server and Blade Server, SUN / Mac OS Support: Windows / Linux / Unix / Mac OS |
| Cables (Option) | Option for 6ft or 15ft DVI-D + USB KVM cable |
| Power supply | Input: Auto-sensing 100 to 240VAC, 50 / 60Hz Power Consumption: Max. 78W, Standby 34W |
| Color | Black (RAL 9005) |
| Environmental | Operating Temperature: 0°C to 55°C Storage Temperature: -20°C to 60°C Relative Humidity: 5~90%, non-condensing Shock: 10G acceleration (11ms duration) Vibration: 10~300Hz 0.5G RMS random vibration |
| Compliance | CE, FCC, RoHS, TAA Compliant |
| Weight | 34.1 lb / 15.5 kg |
| Dimension | 17.3"(W) x 25.6"(D) x 1.73”(H) |
