NOTICE! : PRODUCT EOL

Rack server powered by the single Xeon E5-2600 CPU and ATX motherboard that is integrated into a 1U 25.6-inch depth rackmount chassis.
Loading...

RMC7152

  • 1U high rackmount chassis
  • 25.6 inch depth chassis
  • Xeon E5-2600 processor
  • Embedded ATX motherboard
  • 1 x PCI-E 3.0 x16 expansion slot via riser card
  • 1 x 5.25" & 1 x 3.5" open hard drives
  • 2 x 3.5" internal hard drives
  • 600W power supply
$1,876.00
Availability: In stock
SKU
RMC7152
Email
Rackmount server powered by the Dual Xeon E5-2600 CPUs and embedded motherboard with 2 x open hard drives, 1 x PCI-E 3.0 x16 expansion slot, and 600W power supply in a 1U high 25.6-inch depth rackmount chassis.
Construction
Heavy-duty preplated SPGC cold-rolled steel
Main system
Processor: Dual E5-2600v4 Xeon processor
Memory: 8 x DIMM socket, support DDR4 memory (up to 128GB)
On-board video, Dual LAN, RAID controller & USB ports
Storage Device
1 x 5.25" open drive bay
1 x 3.5" open drive bay
2 x 3.5" hidden drive bays
Expansion Slot
1 x full height PCI-E 3.0 x16 expansion slot
Front Panel Controls
Power on/off switch
System reset button
1 x USB port
Front Indicators
Power, LAN, and HDD LEDs
Rear Connectors
4 x 3.0 USB / 1 x VGA / 2 x LAN / 1 x IPMI
Cooling Fans
Middle: 2 x 40x28mm easy-swap fans
(Optional 3 x 40x28mm fans / 3 x 40x56mm fans)
Rear: 2 x 40x28mm fans
Power Supply
600W power supply
Color
Front Panel: Black
Dimension
19"(W) x 1.75"(H) x 25.6"(D)
Weight
30.8lbs
Environmental
Operating Temperature: 0°C ~ 50°C (32°F ~ 122°F)
Humidity: 5% ~ 95% non-condensing

RMC7152
Rackmount computer, Xeon E5-2600 processor, ATX motherboard, 1 x 5.25" & 1 x 3.5" open drives, 2 x 3.5" internal HD, and 600W 2U power supply.
1U high 25.6 inch depth chassis.

Document
Description
Download Link
file iconRMC7152-SP.pdf
Spec Sheet
  • RMC7152
    1U rackmount server
    E5-2600 Xeon server CPU
    8GB memory
    1 x PCI-E 3.0 x16 expansion slot (full height)
    2 x SATA HD
    600W power supply
    25.6" depth rackmount chassis
    Starting at:
    $1,876.00
RMC7152
$1,876.00

Enclosure
This 1U high and 25.6-inch depth rack mount chassis made by heavy-duty cold-rolled steel. The front panel comes with 1 x USB 2.0 port and LED indicators for power/ HDD / LAN and a power on/off switch and a system reset button.

Storage device
The chassis comes with 1 x 5.25 inch & 1 x 3.5-inch drive bays and 2 x 3.5 inch hidden hard drive bays.

Embedded board
The embedded board power by Xeon E5-2600 processor. The I/O connectors depend on the motherboard layout.

Expansion slots
This rack unit supports 1 x PCI expansion slot via riser card.

Power Supply
The 1U slim-type power supply is located in the rear of the chassis. It comes with a standard 600W power supply.

Mounting
Rack mounting kits come with standard 19-inch rack mounting holes for standard 19-inch rack cabinet.
