3U rack mount computer powered by Core i CPU with ATX mother board and 2 x SATA hard drive open tray in a 3U high 15.7 inch short depth rack mount chassis.
3U high rack mount computer
15.7 inch short depth chassis
Multiple Core processor
ATX mother board with RAID controller
2 x hot-swap SATA HD open tray
7 x open expansion slots
1 x 5.25 inch open drive bay
2U 460W ATX power supply
Rack mount computer powered by Core i CPU and ATX M/B with 7 PCI / PCIe slot, has 2 x open HD tray and 1 x DVD, on board RAID, and x front USB ports and 2U power supply in a 3U high 15.7 inch short depth rack chassis.
Processor: Dual-Core / Quad-Core processor Memory: 4 x DIMM memory sockets (up to 64GB) On board VGA / Ethernet LAN / Audio On board RAID controller Integrated 6 SATA port 4 x USB ports, 2 x USB 3.0 port
2 x hot-swap SATA HD open tray (3.5" HD) 1 x 3.5" internal & 1 X 5.25" open drive bay
Option for 2-port SATA RAID controller add-on card (Support RAID level 0/1)
Front Panel Controls
Power on/off switch System reset button 2 x USB ports 2 x LED indicator for power and HD activity
6 x open expansion slots 1 x PCI-E(x16), 2 x PCI-E(x1), 3 x PCI
Front chassis: 1 x 80mm / 1 x 60mm cooling fan Rear chassis: 2 x 40mm
460W 110/220VAC 2U type ATX single power supply Optional for 2U type 300/400W redundant ATX power supply
RMC8353A Rack mount computer, Core i CPU, ATX mother board with RAID , 2 x SATA HD open tray, 6 x PCI / PCIe Express expansion slot and 300W 2U P/S. 3U high and 15.7 inch short depth chassis.
Dual hot-swappable HDD bay in 3U Form Factor rack mount computer
RMC8353 a compacted 3U rack mount computers achieve a 25% space reduction compared to the standard 4U, whilst still providing 2 x hot-swappable hard drive bay and unrestricted expansion for the add-on cards. The system equipped a standard ATX mother board which supported the latest Intel® Core i5/i7/i3 processors for improved performance and up today technology, the user has up to 7 PCI or PCIe express expansion slots and integrated interface ports includes USB, COM, Video and Ethernet LAN ports which depend on installed mother board I/O layout.
A compacted 3U rack mount chassis made by heavy duty cold rolled electroplated Steel which meet EIA RS-310C Standard with a depth of only 15.7 inch. A shockproof cushioned design secures both 5.25” and 3.5" disk drives, A well designed thermal control system included one front 80mm ( 42.5CFM) fan and two rear 40mm (7CFM each) fans and two rear 60mm (23.5CFM each) fans in place to deliver exceptional thermal performance you can rely on, and a 80-plus high efficiency 460W 2U power supply. The RMC8353 is designed to perform reliably in the harsh working environments.
RMC 8353 comes with 2 hot-swappable hard drive tray, one 3.5-inch and 5.25-inch open drive bay, Two USB ports, HDD / system LED indicators and system reset & ON/OFF switch are on the front panel, and the logo can be customized with any desired nameplate.
Meeting severe environment operational demands in many industries, designed the chassis to operate reliably in a multitude of conditions including 0°C to 50°C (32°F to 122°F) temperatures and EMI shielding. With its excellent flexibility, RMC8355 can serve as either a cost-effective economy solution or a high performance system. It is ideal for power plant master systems, railway control systems and other mission-critical applications.
