NOTICE: PRODUCT EOL. REPLACEMENT PRODUCT IS PC9120 12.1" FANLESS INDUSTRIAL PANEL PC SUPPORTING 800 X 600 RESOLUTION, INTEL PROCESSORS, RESISTIVE TOUCH SCREEN, AND WIDE RANGE 9 TO 36V DC POWER INPUT.

12" HMI computer powered by the Celeron J1900 Quad Core 2GHz processor. It features a 1024 x 768 500-nit LCD panel and touch screen, IP65 rated flat front bezel, and wide range working temperature of -20°C ~ 50°C. Option for RFID reader, magnetic stripe card reader, and projected capacitive multi-touch screen.
Loading...
PMW6242

PMW6242

PC5015

PC5015

PC5012

  • IP65 rated flat front bezel
  • 12.1 inch 1024 x 768 TFT LCD monitor
  • 5-wire resistive type touch screen monitor
  • Option for projected capacitive multi-touch screen
  • Celeron J1900 Quad Core 2GHz embedded computer
  • 500-nits high brightness LCD panel
  • -20ºC to 50ºC wide range working temperature
  • 9~30V DC power input with external AC power adapter
Availability: In stock
SKU
PC5012
Email
Panel PC with 12.1 inch 1024 x 768 touch screen and Celeron J1900 Quad Core 2GHz CPU with fanless cooling system, has an IP65 rated flat front bezel, built-in 802.11 wireless LAN and -20 to 50 degree C wide range working temperature.
Material
IP65 rated rugged enclosure
LCD panel
Size: 12.1”
Max. Resolution: 1024 x 768
Brightness: 500nits
Contrast Ratio: 700:1
Viewing Angel (H/V): 160° x 160°
Pixel Pitch (mm): 0.240(H) x 0.240(V)
Color: 262K
MTBF: 50000 hrs
Touch screen
5-wire resistive type touch screen monitor (RS-232 interface)
Option for projected capacitive type touch screen monitor (USB interface)
System
CPU: Celeron J1900 Quad Core 2GHz CPU
Memory: 2GB 204-pin 1333MHz DDR3 SO-DIMM
Storage: 30GB mSATA SSD & 2.5" SATA HDD bay
Connectors
2 x COM, 1 for RS-232, 1 for RS-232/422/485
4 x USB, 2 for USB 2.0, 2 for USB 3.0
2 x Gigabit Ethernet ports (RJ-45)
1 x power switch
1 x reset button
1 x AT/ATX switch
1 x Audio (Line-out)
1 x 9~30V lockable DC jack
Audio
AMP 3W + 3W internal speaker
Wireless Communication
Built-in IEEE 802.11a/b/g/n/ac 2T2R module
RFID Reader (Option):
Mifare 13.56MHz card reader
Card Reader (Option):
Magnetic Stripe Card Reader
Camera:
2M pixels with low light function
Power supply
9~30V DC power input with external AC power adapter
Mounting (Option)
Wall, Panel, Stand, Rackmount, VESA (75*75mm&100*100mm)
Color
Black
Dimension
7.52”(W) x 1.71”(D) x 5.01”(H)
Environmental
Operating: -20°C to 50°C (-4°F to 122°F)
Storage: -20°C to 60°C (-4°F to 140°F)
Relative humidity: 10% to 95%, non-condensing
Certification
CE, FCC

PC5012:
12.1 inch 1024 x 768 resolutions 500-nit high brightness industrial Panel PC with IP65 rated flat front bezel, Celeron J1900 Quad Core 2GHz embedded computer embedded computer, 2GB DDR3 memory, 30GB mSATA SDD, and 5-wire resistive type touch screen monitor. Option for projected capacitive multi-touch screen.

NOTICE: PRODUCT EOL. REPLACEMENT PRODUCT IS PC9120 12.1" FANLESS INDUSTRIAL PANEL PC SUPPORTING 800 X 600 RESOLUTION, INTEL PROCESSORS, RESISTIVE TOUCH SCREEN, AND WIDE RANGE 9 TO 36V DC POWER INPUT.
Document
Description
Download Link
file iconPC5012-SP.pdf
Spec Sheet
  • PC5012
    Panel PC
    Intel Celeron J1900 1.0GHz Quad Core CPU
    2GB DDR3 memory up to 8GB
    fanless cooling system
    12.1" 1024 x 768 display
    500-nits high brightness display
    Resistive type touch screen
    Option for 6H Projected capacitive type multi-touch screen
    1 x 2.5" SATA hard drive
    Built-in 802.11a/b/g/n/ac wireless LAN moudule
    IP65 rated flat front bezel
    9V to 30V DC power input with external AC adapter
    75mm VESA mount ready
    Starting at:
PC5012

PRODUCT DESCRIPTION
PC5012 is a 12.1" compact HMI touch panel PC powered by the forefront Celeron J1900 Quad Core 2GHz processor with energy efficiency, high dependable touch screens, and long-lasting industrial displays. The system features IP65 rated front bezel and it is waterproof, ingress to dust, maintenance-free, fan-less, able to withstand harsh working environments, resistant to shock and vibration, and ideal for entry-level simple HMI applications. PC 5012 12.1” embedded Panel PCs are powered by the Quad-core Intel Celeron Processor J1900, two COM, four USB, two Gigabit Ethernet ports, audio (line-out), and 9~30V DC wide input-voltage range power supply with an external AC power adapter.

Key Features
• The 12.1” greatly reliable industrial HMI Touchscreen Displays feature: brilliant resolution (1024 x 768), high brightness (500nits), contrast ratio of 700:1, 262K colors, LED-backlight with MTBF at 50,000 hours, thinner profile, and long product life cycle.

• The Touch Panel HMIs from Acnodes offers users a high degree of flexibility for interfaces and expansions, high-speed USB 3.0 and 2.0, high data transfer rate, redundancy and teaming capable Gigabit Ethernet, highly reliable and flexible RS232/422/485 serial communication interfaces; highly flexible graphics and video interfaces with audio ports.

• The Industrial HMI Touch Panel PCs feature: IP65 rated front bezel, rugged enclosure, fan-less, 5-wire resistive type touch screen, the camera of 2M pixels with low light function, and can withstand a wide range of temperatures from -4°F to 122°F. • Alongside Celeron J1900 Quad Core 2GHz, the system contains 2GB 204-pin 1333MHz DDR3L SDRAM DIMM and 30GB mSATA SSD, and a 2.5” SATA HDD bay. It has built-in IEEE 802. 11a/b/g/n/ac wireless communication. The power supply is 9~30V DC power input with an external AC power adapter. The variety of options for wall, panel, stand, rack, or VESA mounted. The option for Mifare 13.56MHz RFID reader and magnetic stripe card reader is available.
